Automatic Swing Gate Operators

It is a wonderful feeling, to sit comfortably in your car while the gate opens itself. The process of getting out of the car just to open the gate seems rather cumbersome. And asides, should there be an emergency, the entire process could be disastrous. As a result of this, I thought it necessary to bring forward a review of the best gate opener.

Basically, InTrust electric gate opener is a practical device that automates the process of opening and closing of gates or the garage doors. There are various types of automatic gate openers that work effectively for various types of gates like the overhead doors, the swing gates, sliding gates, and the 2 leaf or single leaf gate.

The InTrust Remote Electric swing gate opener sets the gate to open or close automatically via a radio transmission without any human assistance. They can be powered either by 12/24 volts. More expensive are solar gate openers which are using solar power.

Automatic Swing Gate operator
Swing gate Motor

Swing Gate Motor 600Kg

Model :

690

Input Voltage :

DC24V

Torque:

8Nm

Rating Power:

65W*2

Remote Distance:

40-60m

Rotation Speed:

55rpm

Running Speed:

0-15m/min

Noise:

≤56dB

Dimension of Gate Opener:

350*130*160mm

Dimension of Control Box:

225*178*88mm

Packing Weight/Set:

22kg

Temperature:

-45℃~+65℃

Max. Gate Width:

≤8m

Max. Gate Weight:

≤600kg

Protection Class :

IP44

Swing gate system

Swing Gate Motor 1000Kg

Model :

T980

Input Voltage :

DC24V

Torque:

12Nm

Rating Power:

100W*2

Remote Distance:

40-60m

Rotation Speed:

50rpm

Running Speed:

0-15m/min

Noise:

≤56dB

Dimension of Gate Opener:

370*200*165mm

Dimension of Control Box:

225*178*88mm

Packing Weight/Set:

32kg

Temperature:

-45℃~+65℃

Max. Gate Width:

≤8m

Max. Gate Weight:

≤1000kg

Protection Class :

IP44

Advantage Rolling Swing Gate Opener

  1. Smooth start and slow stop
  2. Automatically stop against extra resistances
  3. Optional operation mode for single or dual wing
  4. Available for Bluetooth / Mobile phone app control
  5. Interface for card reader and underground detector
  6. Large opening angle ＞180°
  7. Back-up power supply

Features and Benefits Swing Gate Motor

  • Control your Gate through remote, push switch, wifi or keypad

  • Smooth and soft start and stop function

  • Emergency Discharge key in case of Electricity failure.

  • Dual/Single gate running mode Optional master and slave gate running

  • Adjustable opening/closing time interval between master and slave gate

  • Can be Stop/Reverse in case of obstruction during gate opening/closing.

  • The force of the motor can be programmed as per requirement.

  • Optional photocell protection (If Required)

  • Built in adjustable auto-close (As per Requirement)
